Clearance Bar Apparatus

Email sales@bollardsleeves.com or Call 1-800-914-4771 for Pricing

Request a Quote

Clearance Bar Materials:

  • Lo-Density Thermoplastic Polyethylene (LDPE)
  • W/ Ultra-Violet And Anti-Static Additives
  • .250 Nominal Wall Thickness

Clearance Bar sizes:

  • Length :78”
  • 5.25” Outside Diameter
  • Weight: 15 lbs
  • Lettering: Optional

Clearance Bar Installation:

  • Simple installation: eyebolts included with order
  • (chains not included)

Clearance Arm Materials:

  • 1-Β½ schedule 40 steel, sleeved with HDPE plastic
  • HDPD Plastic Standard Colors: yellow, red, black, blue other colors available
  • Standard Heights: 10 ft.
  • Standard Cross Bar length: 10 ft.
  • Fittings: Alloy Magnesium, will not rust
  • (Optional) Swing Collar Mechanism to return Clearance Arm back to Home Position when hit.

Steel Bollard Size Options - includes Sleeve Cover:

  • 4’’ schedule 40 steel with plastic sleeve cover
  • 6’’ schedule 40 steel with plastic sleeve cover
  • Sleeve Cover Standard Colors: yellow, red, black, blue other colors available
  • Standard Length :36’’, 42’’, 48’’, and 52’’ ( custom lengths available)
  • Installation Options: Plate Mount or Core-In
  • Base Plate Dimensions: 10’’ x 10’’ x 5/8’’ – ( 4) 15/16th Anchor bolt holes
  • (Optional) (4) ¾’’ x 6 ¼’’ Anchor Bolts

Product Details:
